Description
H96 MAX PRO Android 10 TV Box 4GB RAM 64GB Rom 4K 1080p 2.4G&5G Wifi Bluetooth H616 Quad Core Youtube TV BOX Set Top Box
CPU:Allwinner H616 Quad Core ARM Cortex A53
GPU:G31MP2
Memory:2GB/4GB DDR3L
Flash:16G/32GB/64GB eMMC
WiFi/BT:2.4GHz 5GHz with BT4.0
1*HDMI :HDMI 2.0a up to 4K@60fps
2*USB:1 * USB 3.0 ; 1*USB 2.0
1*IR Reciver:Remote Reciver Connect
1*RJ45:Ethernet Interface;Support 10/100M
1*TF Card:Support 4GB/8GB/16GB/32GB/64GB
OS:Android 10.0
Power:DC 5V/2A
Language:English French German Spanish Italian etc multilateral languages
| H96 Max H616 | ||
| CPU | Allwinner H616 Quad CoreARM Cortex A53 | |
| GPU | G31MP2 Supports OpenGL ES 3.2/2.0/1.0, Vulkan 1.1, OpenCL 2.0 | |
| Memory | 2GB/4GBDDR3L | |
| Flash | 16G/32GB/64GBeMMC | |
| WiFi/BT | 2.4GHz+5GHz with BT4.0 | |
| I/O | 1*HDMI | HDMI 2.0a up to 4K@60fps |
| 1*AV OUT | 480i/576i standard definition output;CVBS output, supporting PAL/NTSC | |
| 2*USB | 1 * USB 3.0 ; 1*USB 2.0 | |
| 1*IR Reciver | Remote Reciver Connect | |
| 1*RJ45 | Ethernet Interface;Support 10/100M | |
| 1*TF Card | Support 4GB/8GB/16GB/32GB/64GB | |
| OS | Android 10.0 | |
| Power | DC 5V/2A Power ON :blue | |
| Support | Support USB,pre-install APK | |
| Certification | CE,Rohs,Fcc and Health test reports ,safe shipment reports,etc... | |
| Accessories | Power Adapter,HDMI cable,AV cable,Remote controller,Gift box | |
| Language | English French German Spanish Italian etc multilateral languages | |
| Image | JPG,JPEG,BMP,GIF,PNG,TIF | |
| Video | Video Engine (AVE) with dedicated hardware decoders and encoders Support multi-video decoder up to 4Kx2K@60fps+1x1080P@60fps Supports multiple "secured" video decoding sessions and simultaneous decoding and encoding Video Decoding - VP9 Profile 2 up to 4Kx2K@60fps - H.265 Main10@L5.1 up to 4Kx2K@60fps,or 6K@30fps - AVS2-P2 Profile up to 4Kx2K@60fps - H.264 BP/MP/HP@L4.2 up to 4Kx2K@30fps - H.263 BP up to 1080P@60fps - MPEG-4 SP/ASP@L5 up to 1080P@60fps (ISO-14496) - MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) - MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) - Xvid up to 1080P@60fps - Sorenson Spark up to 1080P@60fps - VP8 up to 1080P@60fps - AVS/AVS+ JiZhun Profile up to 1080P@60fps - WMV9/VC1 SP/MP/AP up to 1080P@60fps - JPEG HFIF file format up to 45MPPS - Multiple language and multiple format sub-title video support - MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) - Supports JPEG thumbnail, scaling, rotation and transition effects - Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats |
|
| Audio | Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing Audio Codec -Two audiio digital-to-analog(DAC) channels -Support 16-bit and 20-bit sample rate -8kHz to 192kHz DAC sample rate -95+/-2dB SNR@A-weight,-80+/-dB THD+N,output Level more than 0.55Vrms -One128*24-bits FIFO for DAC data transmit built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x32bits x 8ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 8ch Digital microphone PDM input with programmable CIC, LPF & HPF, support up to 8 DMICs Built-in stereo audio DAC Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM |
|
| Packing | Product dimension | 90mm*90mm*17mm |
| Qty per unit packing | 1pc | |
| Unit packing: (LxWxH) | 173*103*65mm | |
| Unit packing (G.W.) | 300g | |
| Qty per export carton | 20PCS | |
| Export carton (WxHxL) | 365*345*220mm | |
| Export carton (G.W.) | 6.4KG | |
✔ 1 x H96 Max Android 10 Tv Box
✔ 1 x Remote control
✔ 1 x Power Supply
✔ 1 x HD Cable
✔ 1 x User Manual
