There are 4 models optional, please place order according to your actual needs:
1) Multi-function Model: 3.5mm earphone port, 3.5mm mic port, 2-in-1 3.5mm port, microphone-mute button, earphone-mute button, with volume control; 15cm/100cm cable length available.
2) Multi-function with Type-C OTG Model: 15cm Multi-function Model, add a type-c female to usb female adapter, 15cm cable length.
3) Multi-sound Model: 3.5mm earphone port, 3.5mm mic port, with 4 sound modes; 15cm cable length.
4) Basic Model: 3.5mm earphone port, 3.5mm mic port, 15cm cable length.
External USB Sound Card
Ugreen usb audio adapter aims to solve your problems of missing audio adapter, or 3.5mm audio adapter no working, greatly immerses yourself in the fantastic audio world.
- Dimension: 74 x 34 x 15.5mm (LxWxH)
- Output: (1) 3.5mm headphone jack
(2) 3.5mm mono microphone jack
(3) 4-pin combo Mic/headphone jack (Only support CTIA)
- SNR: ≥85dB
- Sampling Rate: 16bit 48KHz
- Time Delay: 40 - 50mS
- Frequency response: 20Hz - 20KHz
- With function of disabling headphone Mic and volume control
- No driver required for Windows/Mac OS/Linux
- Ensure usb audio adapter is set to be your primary playback and recording device in your control panel or system preferences.
- The 4-pin combo Mic/headphone jack only support TRRS CTIA standard, does not support TRRS OMTP standard
- The input of microphone jack and combo Mic/headphone jack only support mono
- Please make sure your phone supports OTG function when using it on the phones
