Processor
- CPU: Intel Celeron 3205U
Memory
- Capacity: Single-channel SODIMM slot for supporting DDR3L 1066/1333/1600MHz, Support Max 8GB
Display
- VGA: Supports up to 2650×1600@60Hz resolution
- HDMI: Supports up to 1920×1200@60Hz resolution
- Dual Display: VGA+HDMI supports synchronous and asynchronous display
LAN
- LAN1: 10/100/1000 Mbps Realtek 8111F, Support WAKE ON LAN
- LAN2: 10/100/1000 Mbps Realtek 8111F, Support WAKE ON LAN
Audio
- Main System: Realtek ALC662 audio control chip, support dual channel, stereo, Line out
I/O
- USB: 2×USB3.0, 2×USB2.0
- COM: 2×RS-232
Extension
- Mini-PCIE: 1 x half-height Mini PCIE
Storage
- HDD: Support SATA 2.5" HDD (Data conversion rate SATA 2.0)
- SSD: 1 x full height mSATA socket
OS Software
- Windows: Windows 7, Windows 8, Windows 10
- Linux: Ubuntu, Linux, CentOS
Power
- DC-IN: 5.5*2.5
- Power Voltage: 12V
- Power Input: 3A
- Power Adapter: DC 12V 3A/36W (AC TO DC, 100~240V)
- Power CPU: 10W
Material
- Body: Aluminum Alloy
Install
- Mounting Options: VESA/Wall-mounted/Desktop
Dimensions
- Size: 13612839mm
- Weight: 0.65KG
- Color: Black
Environmental
- Operating Temperature: -20℃~+65℃
- Storage Temperature: -20℃~+75℃
- Operating Humidity: 5% to 95% relative humidity, no condensation
